Test method | Measure methods include End-point, Two point, kinetic, reagent blank sample blank, immunity nephelometery, and multiplicate selectable calibration methods, such as multi-standards, linear or non-linear calibration curves etc) | |
Optics | 7 wavelengths 340nm, 405nm, 505nm, 546nm, 578nm, 620nm, 670nm. | |
Light source | 6V/10W Halogen Lamp with long life span light path 10mm, auto-sleep function | |
Precision | ±2nm | |
Width | ≤10nm | |
Absorbance range | 0.000~3.000 Abs | |
Linearity | ≤1% | |
Resolution | 0.001ABS | |
Cross contamination Rate | ≤1% | |
Aspirate volume | >100μl | |
Absorbency repeatability | CV≤1% | |
Flow cell | 32μl quartz flow cell | |
Sample volume | 50μl to 3000μl | |
Memory | 200 test programs, over 100,000 test results | |
Display | 5 inch color LCD with touch screen | |
Printer | Built-in thermal printer | |
Connection | RS-232 interface | |
Language | Multi-language version such as Chinese,English, Russian, Spanish etc | |
Working temperature | 10℃~30℃ | |
Humidity | 30%~80% | |
Power supply | 100-240 VAC, 50/60 Hz, 100VA | |
Instrument Dimension | 420mm*310mm*150mm(L*W*H) | |
Instrument Weight | 5Kg |
Comprehensive reagent menu | ||
Hepatic Panel | Pancreatitis | |
Renal Panel | Cardiac Panel | |
Lipid Panel | Inflammation Panel | |
Immune Panel | Iron Metabolism | |
Diabetes | Rheumatoid |
Model | G.W/KG | N.W/KG | Carton Size/CM | Volume/CBM | Remark |
WP21B | 8 | 5 | 45x42x35 | 0.07 | 1 Carton |
